Pump 230V - ARS pump (Invensys pump) - oscillating piston pump Electrical connection: 230V/50Hz 60Hz Power: 65W Inlet: 7 mm Outlet: 14 mm Connection: 6,3 mm plug-in lug

Elektroanschluss: 230V/50Hz Leistung: 28 Watt Umfang der Spule: 35 mm Länge der Spule: 33mm Gesamtlänge der Schwingkolbenpumpe: Eingang/Ausgang 90 mm Einbauhöhe: 43 mm

OLAB 14000 pump, condensate pump, oscillating piston pump, dosing pump, water pump, for Waeco SP 950T truck parking cooler CoolAir SP 950 This pump replaces or is compatible with CEME ET 200. Voltage: 24V AC Power: 29VA ED100%, Class H 330 cm3/min self-priming   Further technical details (see picture):          1.    water outlet: brass body up to Ø 7 mm         2.    brass capsule TN-UNI EN12165-CW614N         3.    piston made of stainless steel         4.    water inlet: stainless steel connection up to Ø 6,2 mm         5.    gasket: fixed core made of PTFE         6.    POM anti-adhesive bushing (PTFE with FKM seals)         7.    springs made of stainless steel         8 .   lip seal (NBR or FKM) 3         9.    sealing O-rings (NBR or FKM)       10.    small head sealing (silicone or FKM)       11.    thermal class of coil: Class H

Diaphragm pump 220V-240V self-priming / vibration pump Voltage: 220-240V 50Hz Power: 9W Inlet: Ø 3 mm Outlet: Ø 3 mm Length: 54 mm Self-priming

Dosing pump / diaphragm dosing pump: Electrical connection: 220-240V 50/60Hz Power: 9W Inlet: Ø 3 mm Outlet: Ø 3 mm Length: 54 mm TA 60C Class H self-priming

OLAB 14000 Kondensatpumpe Diese Pumpe ersetzt bzw. ist kompatibel mit CEME ET 200. Spannung: 230V 50Hz, Leistung: 19W Spannung: 24V AC, Leistung: 29VA ED100%, Classe H 330 cm3/min selbstsaugend weitere technische Details (siehe Abbildung):1. Wasserausgang Messinggehäuse bis Ø 7mm2. Messinghülse TN-UNI EN12165-CW614N3. Kolben aus Edelstahl4. Wassereingang Edelstahlanschluss bis Ø 6,2mm5. Dichtung fester Kern aus PTFE6. POM-Antihaftbuchse (PTFE mit FKM-Dichtungen)7. Federn aus Edelstahl8. Lippendichtung (NBR oder FKM) 39. Abdichtung von O-Ringen (NBR oder FKM)10. kleiner Kopf abdichten (Silikon oder FKM)11. Wärmeklasse der Spule Classe H

OLAB 14000 dosing pump 230V or 24V AC Voltage 230V 50Hz - Power 29VA 19W - ED100%, Class H Voltage 24V AC - Power 29VA - ED100%, Class H Pressure range: 1,2bar 330 cm3/min self-priming Other technical details (see picture):          1.   water outlet: brass body up to Ø 7 mm         2.   brass capsule TN-UNI EN12165-CW614N         3.   stainless steel piston         4.   water inlet: stainless steel connection up to Ø 6,2 mm         5.   gasket: fixed core made of PTFE         6.   POM anti-adhesive bushing (PTFE with FKM seals)         7.   stainless steel springs         8.   lip seal (NBR or FKM) 3         9.   sealing O-rings (NBR or FKM)        10.  small head sealing (silicone or FKM)        11.  thermal class of coil: Class H

OLAB 14000 oscillating piston pump 230V - compatible with Abund oscillating piston pump Voltage: 230V 50Hz Power: 29VA 19W ED100%, Class H Self-priming: 330 cm3/min This pump replaces the following Abund series: Abund 208-18-101 Abund 208-18-101-0 Abund 208-18-102 Abund 208-18-103-0 Other technical details (see picture):          1.   water outlet: brass body up to Ø 7 mm         2.   brass capsule TN-UNI EN12165-CW614N         3.   stainless steel piston         4.   water inlet: stainless steel connection up to Ø 6,2 mm         5.   gasket: fixed core made of PTFE         6.   POM anti-adhesive bushing (PTFE with FKM seals)         7.   stainless steel springs         8.   lip seal (NBR or FKM) 3         9.   sealing O-rings (NBR or FKM)        10.  small head sealing (silicone or FKM)        11.  thermal class of coil: Class H

OLAB 14000 oscillating piston pump 230V - compatible with Abund oscillating piston pump Voltage: 230V 50Hz Power: 29VA 19W ED100%, Class H Self-priming: 330 cm3/min This pump replaces the following Abund series: Abund 208-18-101 Abund 208-18-101-0 Abund 208-18-102 Abund 208-18-103-0 Other technical details (see picture):          1.   water outlet: brass body up to Ø 7 mm         2.   brass capsule TN-UNI EN12165-CW614N         3.   stainless steel piston         4.   water inlet: stainless steel connection up to Ø 6,2 mm         5.   gasket: fixed core made of PTFE         6.   POM anti-adhesive bushing (PTFE with FKM seals)         7.   stainless steel springs         8.   lip seal (NBR or FKM) 3         9.   sealing O-rings (NBR or FKM)        10.  small head sealing (silicone or FKM)        11.  thermal class of coil: Class H

OLAB 14000 pump for Waeco air conditioner Waeco CA 800 Waeco CA 1000 230V This pump replaces or is compatible with CEME ET 200. Voltage: 230V 50Hz Power: 29VA 19W ED100%, Class H 330 cm3/min self-priming Further technical details (see picture):          1.   water outlet: brass body up to Ø 7 mm         2.   brass capsule TN-UNI EN12165-CW614N         3.   piston made of stainless steel         4.   water inlet: stainless steel connection up to Ø 6,2 mm         5.   gasket: fixed core made of PTFE         6.   POM anti-adhesive bushing (PTFE with FKM seals)         7.   springs made of stainless steel         8.   lip seal (NBR or FKM) 3         9.   sealing O-rings (NBR or FKM)        10.  small head sealing (silicone or FKM)        11.  thermal class of coil: Class H

OLAB 14000 water pump 24V AC and 230V Electrical connection 230V 50Hz - Power 29VA 19W - ED 100%, Class H Electrical connection 24V AC 50Hz - Power 29VA - ED 100%, Class H Pressure Range: 1,2bar 330 cm3/min self-priming This oscillating piston pump is suitable among others for: Bomann DBS 778 CB AEG DBS 5558 AEG DBS 5564 AEG DBS 2300 Leifheit Dressfix Quadro Clean Maxx Steam broom XXL Severin BA 3299 Quigg DBS 3000 Quigg DBS 5000 Clatronic DBS 3461 Clatronic DBS .... Grundig SIS 8250 Morphy Richards Jet Stream 42272 Singer SG300SR further technical details (see picture):             1.   water outlet: brass body up to Ø 7 mm         2.   brass capsule TN-UNI EN12165-CW614N         3.   stainless steel piston         4.   water inlet: stainless steel connection up to Ø 6,2 mm         5.   gasket: fixed core made of PTFE         6.   POM anti-adhesive bushing (PTFE with FKM seals)         7.   stainless steel springs         8.   lip seal (NBR or FKM) 3         9.   sealing O-rings (NBR or FKM)        10.  small head sealing (silicone or FKM)        11.  thermal class of coil: Class H

Water pump 230V in 28W or 48W - OLAB 22000 OLAB series 22000-04: voltage 230V/50Hz - power 28W OLAB series 22000-15: voltage 230V/50Hz - power 48W Inlet: 7 mm Outlet: 14 mm Connection: 6,3 mm with plug-in lug

Thread: G1/8 inch = 9.7 mm Matrial: Brass applicable in: OLAB - Ulka - Ivensys and other manufacturers of water pumps/vibratory pumps
